Sick LUT3-990 1019291 Cảm biến phát quang Sick Vietnam

Danh mục: Sick Vietnam

Sick LUT3-990 1019291 Cảm biến phát quang Sick Vietnam

100% EU/ Germany Origin

Sick Vietnam

Code: 1049066
WL9-3P3430
Small photoelectric sensors

LUT3-990

100% EU/ Germany Origin

Sick Vietnam

Code: 1019291
LUT3-990
Luminescence sensors

100% EU/ Hungary Origin

Sick Vietnam

Code: 1043783
FX3-CPU000000
Safe EFI-pro System / Flexi Soft / Main module

Dimensions (W x H x D)	30.4 mm x 53 mm x 80 mm
Sensing distance	90 mm ¹⁾
Housing design (light emission)	Rectangular
Light source	LED, Ultraviolet light ²⁾
Wave length	375 nm
Light spot size	12 mm x 12 mm
Receiving filters	KV 418 (standard)
Receiving range	450 nm … 750 nm
Adjustment	Potentiometer
Output function	Light switching

Supply voltage	12 V DC … 30 V DC ¹⁾
Ripple	< 2 V_pp ²⁾
Current consumption	< 60 mA ³⁾
Switching frequency	1.5 kHz ⁴⁾
Response time	350 µs ⁵⁾
Switching output	PNP, NPN
Switching output (voltage)	PNP: HIGH = V_S– ≤ 3 V / LOW = approx. 0 V NPN: HIGH = approx. V_S / LOW ≤ 2 V
Switching mode	Light switching
Output current I_max.	100 mA
Connection type	Male connector M12, 5-pin
Protection class	II ⁶⁾
Circuit protection	U_V connections, reverse polarity protected Output Q short-circuit protected Interference pulse suppression
Enclosure rating	IP67
Weight	400 g
Housing material	Metal, zinc diecast
