RIF600P-S2H-M2H Riels instrumens Clamp-on Ultrasonic flowmerter

Art-n: RIF600P-S2H-M2H

Clamp-on Ultrasonic flowmerter. Portable version.
Ultrasonic transit-time principle
Accuracy Flow: Better than ±1%
Dispaly LCD display with English, Italian language
LCD dispaly can display the instant Flow rate, total Flow, Velocity, Quality parameters, System errors
Turbidity 10000 ppm and with little bubbles
Velocity 0…±32 ms
Operationg enviroment
Transmitter: -20…+60°C;
Transducer:-30…+160°C
Humidity Transmitter: 85%RH;
transmitter protection grade:IP65
Power supply Three internal 1.2V,2000mAH rechargeable Ni-MH battery. Can work 12 hours fully charged.
Can achieve continuous measurement with AC100-240V power adapter
Consumption 1.5W
transmitter’s case material: Flame retardant ABS
Weight Transmitter: 514g
the suitcase contains:

vali chứa:
n. 1 couple of S1H (IP68) clamp-on ultrasonic sensor DN15÷DN100 with 5 m cable. Temperature -30…+160°C
n. 1 couple of M1H (IP68) clamp-on ultrasonic sensor DN50÷DN700 with 5 m cable. Temperature -30…+160°C
n. 1 RS232 converter
n. 1 Power supply AC 110…240V
n. 1 meter roller
n. 4 fastening clamps
n. 1 Test report 3 points
