USM Tension/compression type load cell
Product outline
Safe overload of 500% ! Miniature tension/compression loadcell.
- Capacity 1 N / 2 N / 5 N / 10 N / 20 N / 50 N
- Ultra-compact size: 11W×14H×4D mm
- Safe overload rating of 500% !!
- Suitable for measurement of thread tension and plunger force for needle and syringe.
Very compact
Space-saving design. Ideal for side-by-side installation too.
![USM](https://www.unipulse.tokyo/en/wp-content/uploads/2018/02/USM_small.jpg)
Easy to install
Two tapped holes at both hands enable easier connections to the actuator.
![USM](https://www.unipulse.tokyo/en/wp-content/uploads/2018/02/USM_tap.jpg)
Great durability
Loadcell frequently gets damaged especially in small force measurement, and cable is easily broken.
![USM](https://www.unipulse.tokyo/en/wp-content/uploads/2018/02/USM_hs.jpg)
Safe overload of 500%! Using high durability robot cable!
Specifications
Model | USM-1N USM-2N |
USM-5N USM-10N USM-20N USM-50N |
|
---|---|---|---|
Rated capacity | 1, 2 | 5, 10, 20, 50 | N |
Rated output | Approx. 0.4 | mV/V | |
Safe overload | 500 | %R.C. | |
Zero balance | ±0.3 | mV/V | |
Non-linearity | 0.2 | 0.1 | %R.O. |
Hysteresis | 0.2 | 0.1 | %R.O. |
Repeatability | 0.1 | %R.O. | |
Compensated temperature range | -10 to +60 | ℃ | |
Safe temperature range | -20 to +70 | ℃ | |
Temperature effect on zero | 1 | %R.O./10℃ | |
Temperature effect on span | 1 | %R.O./10℃ | |
Input resistance | Approx. 1000 | Ω | |
Output resistance | Approx. 1000 | Ω | |
Recommended excitation voltage | 5 | V | |
Maximum excitation voltage | 7.5 | V | |
Insulation resistance | 1000 or more | MΩ | |
Cable | φ2mm 4-conductor flexible cable (1m) Cable end: 5 wires | ||
Cable color code | +EXC:Red +SIG:Green -EXC:(Black/Blue) -SIG:White SHIELD |
||
Loadcell material | Aluminum alloy | ||
Deflection at rated | 1N:0.006 2N:0.007 5N:0.005 10N:0.011 20N:0.011 50N: 0.023 |
mm | |
Natural frequency | 1N:2.7 2N:3.1 5N:3.8 10N:3.3 20N:4.1 50N: 4.3 |
kHz | |
Weight | Approx. 2 (Excluding the cable) | Approx. 3 (Excluding the cable) | g |
RoHS directives | 2011/65/EU (EU)2015/863 |
External dimension
![External dimension](https://www.unipulse.tokyo/en/wp-content/uploads/2018/02/USM_dimension_e.gif)
