ZEF-200 Hans Schmidt – Máy đo lực căng dây Hans Schmidt Việt Nam

3 Tension ranges available
from 0.5 – 50 cN up to 1.0 – 200.0 cN

For fibers up to 200 tex and Cu wire Ø 0.16 mm

Economical electronic tension meter for measuring low tensions of fibres, threads and fine wires

Hand-held device with slim filament guide and small guide rollers groove Ø 7.4 mm for limited access space

Model	Measuring Range	Resolution	Measuring Head Width*	SCHMIDT Calibration Material**
ZEF-50	0.5 – 50.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø
ZEF-100	0.5 – 100.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø
ZEF-200	1.0 – 200.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø

Tension meter ZEF with coloured, backlighted TFT display

3 different display modes
– numeric
– numeric with live bargraph
– numeric with graph (time-tension)

The display rotates in 90° steps for better reading

Automatic “Zero-Setting” in each measuring position using a special sensor technique

Selectable units of measurement: cN, g, N and lb

Very high data sampling rate (internal 1 kHz)

Storage of MIN, MAX, last reading, average and standard deviation per measuring interval

User-set MIN and MAX alarms with indication of TFT display if reading is out of limits

Adjustable electronic damping for better reading when tension fluctuates

3 separate calibration material memory locations for custom calibrations

Menu set-up in English, German, Spanish, Portuguese and French language

Slim filament guide with small guide rollers – ideal for limited access space

Simple, trouble free operation

Filament guide and unique roller shifting mechanism ensure easy acquisition of the running material

Light weight hand-held unit

Everything in operator’s view:
– the guide rollers
– the measuring material
– the readings

Ball-bearing mounted, V-grooved guide rollers

Tension meter with high-strength plastic housing

LiPo accumulator (approx. 25 hours continuous operation) with AC adapter

CE approved (tested for electromagnetic compatibility)

Certificate of Compliance with the order 2.1 according EN 10204 is included

Optionally available: Inspection Certificate 3.1 according EN 10204 with calibration report
