Safety locking device L200-M1C3-SLM24-PB-L2G 63000652 Leuze Vietnam
| 100% Germany Origin | Leuze Vietnam | Code : L200-M1C3-SLM24-PB-L2G P/N : 63000652 Description: Metal bodied interlocking device. Energize solenoid to unlock E-release button. 24VDC. Solenoid:[2*NC] Actuator:[1*NC+1*NO] Creep contacts. Max 500V 10A. Actuator approach directions x 5. 3xM20 entries. LED indication. Use with AC-AHL-(x) actuator types |
L200-M1C3-SLM24-PB-L2G Safety locking device
Part no.: 63000652
| Series | L200 |
| Functions | Auxiliary release Emergency release Illuminated displays for magnet activation Integration in control circuits up to category4 in accordance with EN ISO 13849-1 Locking device with guard interlocking according to ISO 14119 Mechanical guard interlocking (spring-force) |
| Operating principle | Quiescent current principle – Actuator locked if electromagnet is deactivated |
| Mission time | 20 years, EN ISO 13849-1 |
| B10d | 5,000,000 number of cycles |
| Usage category at DC 13 | Ue / Ie: 24 V / 3 A, 125 V / 0.7 A, 250 V / 0.4 A, EN 60947-5-1 |
| Usage category at AC 15 | Ue / le: 120 V / 6 A, 250 V / 5 A, 400 V / 3 A, EN 60947-5-1 |
| Contact allocation, actuator | 1NC + 1NO |
| Contact allocation, magnet | 2NC |
| Contact opening | Force-fit |
| Magnet operating voltage | 24 V DC, -10 … 10 % |
| Short circuit protection, magnet | 0.5 A, 24 V, type gG, IEC 60269-1 |
| Short circuit protection, safety circuit | 500 V, 10 A, type gG, IEC 60269-1 |
| Rated insulation voltage | 400 V AC, 300 V DC |
| Conventional thermal current, max. | 10 A |
| Teach input for actuator | No |
| Switch-on time | 100 % |
| Number of connections | 1 Piece(s) |
| Number of cable entries | 3 Piece(s) |
