ECTOR INVERTERSOHO VD

• 3.7 ~ 200kW / 200V ㅣ 5.5 ~ 800kW / 400V ㅣ 30 ~ 630kW / 690V ㅣ 110 ~ 630kW / 1140V

SOHO VD is vector inverter as the best solution with various function and highly performance.

Auto-tuning function and built-in PID Controller make to maximize convenience for users.
Sensorless and Sensored Vector Control ensures stable control performance.
SOHO VD meets the needs of variety of customers.

Protection Function

• Over Current / Over Voltage / Low Voltage / Over Heat / Over Load / Zero-Sequence Current / Unusual operation etc.

Powerful Torque Control

• High torque at Low Speed
• Available 150% Torque at Starting
• Accuracy Torque Control with no Feedback
• Faster Torque Response even though rapidly variable loads
• Counter Deceleration Control
• Zero Speed Control

Synchronous Control / Double Speed Control

• Speed-Speed Control
• Torque-Speed Control

Improved PID Control

• The built-in PID Controller controls flow, temperature, pressure and etc. through the proportional, integral and differential calculus between the feedback value and reference value in the closed loop.
• PID Compensation function is available.

Various Communication Program

• Profibus, Modbus, RS485/232C, CAN
• To control an inverter on your PC with using MMI Program (Seoho Drive Manager) :
  Monitoring, Fault Trace, Free Function Block and etc.

Improved Trouble Shooting

• Saving the inverter conditions included trace data of current, voltage, frequency, torque and etc. for a second before the inverter is tripped.

Auto Tuning

• Optimized performance through measuring the parameters of motor automatically with simple operate (Sensorless Vector Control, Sensored Vector Control)

Main Voltage

• 200V / 400V / 690V / 1140V

Control Method

• Sensorless V/F Frequency Control
• Sensorless Vector Speed Control
• Sensorless Torque Control
• Sensored Vector Speed Control
• Sensored Torque Control
