Hall sensors MHRM 12G2501 Baumer việt nam – Đại lý Baumer việt nam
sensors MHRM 12G2501
Article no.: 10136428
Hall sensors
- cable FEP, 2 m
- -40 … 120 °C
General data
- Version
- Full metal
- Sensor type
- Hall sensor
- Working distance max.
- <0,5 mm (module 1), <2,5 mm (module 3)
- Min. gear size
- > module 1
- Gear width
- > 6 mm
- Gear material
- ferromagnetic
Electrical data
- Switching frequency range
- 0 … 15 kHz
- Voltage supply range +Vs
- 8 … 28 VDC
- Current consumption max. (no load)
- 20 mA
- Output A
- Push-pull
- Output B
- Push-pull
- Voltage drop Vd
- <5 VDC
- Short circuit protection
- Yes
- Reverse polarity protection
- Yes, Vs to GND
Mechanical data
- Design
- Cylindrical threaded
- Housing material
- Stainless steel
- Dimension
- 12 mm
- Housing length
- 60 mm
- Installation aid
- Keyway
- Connection types
- Cable FEP, 2 m
- Front of sensor durable against pressure
- 20 bar
