ANRITSU A-233E-01-1-TC1-ASP ANRITSU Việt Nam

General Stationary Suface Probes Model A series
Type E : Model A-233E-01-1-TC1-ANP
Type K : Model A-233K-01-1-TC1-ANP

Back

Product Info

Temp. range: -50°C to 500°C

Tolerance: -50°C ≦ t < 333°C : ±2.5°C
333°C ≦ t ≦ 500°C : ±(0.0075 × | t |)°C
* t : Measured temperature

Response time: 1.5 s

Durability: More than 75,000 contacts

Cable type and length: Type E : TC-E 1m
Type K : TC-K 1m

Plug: Type E : ANP-E-M-L
Type K : ANP-K-M-L

Repair: Repairable

Remarks

* The operating temperature limit is determined by the allowable temperature limit of the probe head contacts the measurement target.
Note that the operating temperature limit is not the same as the allowable temperature limits of the grip,cable,and plug.
* The response time is the time required to detect 99% of the true value on a flat and smooth metal surface.
* Number of contacts enabling measurement within the tolerance range on a flat and smooth metal surface at a temperature of 300°C (or at the operating temperature limit if the operating temperature limit is below 300°C).
* Please contact the distributor for price and delivery.
