Active Cube Series

The Bonfiglioli Active Cube is a frequency inverter offering both compactness and flexibility. This specific solution is adaptable on a wide range of machines, starting from servo to heavy industry applications. The broad support for various field bus systems and the standardized interface for motion control applications make Active Cube an excellent jack of all trades for your application needs.

Main options

• Different Field bus options like CANopen, PROFIBUS, Modbus, EtherCAT, PROFINET, Varan
• Optional I/O extensions for addtional digital and analogue inputs & outputs
• Optional Keypad for diagnosis and parameter setup
• Optional PC Interface
• Optional accessories like brake resistor, mains chokes, mains filters
Degree of protection

IP20 (EN 60529)
Certifications

UL508c
STO (EN13849 / EN 61508)
Conformity

CE
EN61800
Power supply & Power range

ACU410: 0,25 – 400 kW / trifase 360 – 480V / 50 – 60 Hz ( 10%)
Connessione in parallelo fino a 1200 kW

ACU210: 0,25 – 9,2 kW / mono o trifase 200 – 240V / 50 – 60 Hz ( 10%)

ACU510: 160 – 400 kW / trifase 525V / 50 – 60 Hz ( 10%)
Connessione in parallelo fino a 1200 kW

ACU610: 160 – 400 kW / trifase 690V / 50 – 60 Hz ( 10%)
Connessione in parallelo fino a 1200 kW
Hardware features

• Integrated safe torque off (ACU410: STO SIL 3 / PL e) function
•External 24Vdc supply
•Integrated dynamic braking module
•DC link connection
•Standard HTL encoder interface
•Motor temperature monitoring
•Plug-in power terminals (up to 3kW)
•Plug-in and programmable control terminals
•6 digital inputs, 1 multifunction input
•1 digital output, 1 multifunction output
•1 relay output (changeover contact)
Software features

Main software features
• Positioning function standalone through table motion profiles
• Positioning function via field bus (Motion Control compatible to CiA DS402)
• Rotary table control
• Master/slave function with electronic gear
• Power failure control
• Functions for lift, crane and winch applications
• Spindle control
• Traverse function for winders
• Programmable reference value channel
• Programmable start and stop characteristics
• Motor potentiometer
• Programmable S curve
• 4 data sets
• Auto startup and commissioning
• Auto reset after failure
• Auto start after power failure
• PI controller
• Volume flow control
• Jerkfree torque/speed changeover
• Mechanical brake control free of friction
• Index control
• Intelligent current limits
• Comprehensive monitoring and protection capabilities
• High-speed control
• 3 different brake management functions
Mounting options

• Cabinet mounting for all sizes
• Optional feed-through mounting
• Optional DIN rail mounting frame
Output

0 … 599 Hz
Motors

• Motor compatibility
• Asynchronous AC motors
• Permanent magnet synchronous (brushless) motors
• Reluctance motors
Motor options

Motor Control (open loop or optional closed loop):
• Asynchronous AC motors
• Synchronous Reluctance motors
• Permanent magnet synchronous(brushless) motors

TYPES & POWERS (ACU 210)

Type | Size | Power kW*
ACU 210- 01 | 1 | 0.25
ACU 210- 03 | 1 | 0.37
ACU 210- 05 | 1 | 0.55
ACU 210- 07 | 1 | 0.75
ACU 210- 09 | 1 | 1.1
ACU 210- 11 | 2 | 1.5
ACU 210- 13 | 2 | 2.2
ACU 210- 15 | 2 | 3
ACU 210- 18 | 3 | 4
ACU 210- 19 | 3 | 5.5
ACU 210- 21 | 4 | 7.5
ACU 210- 22 | 4 | 9.2
TYPES & POWERS (ACU 410)

Type | Size| Power kW*
ACU 410- 01 | 1 | 0.25
ACU 410- 03 | 1 | 0.37
ACU 410- 05 | 1 | 0.55
ACU 410- 07 | 1 | 0.75
ACU 410- 09 | 1 | 1.1
ACU 410- 11 | 1 | 1.5
ACU 410- 12 | 2 | 1.85
ACU 410- 13 | 2 | 2.2
ACU 410- 15 | 2 | 3
ACU 410- 18 | 2 | 4
ACU 410- 19 | 3 | 5.5
ACU 410- 21 | 3 | 7.5
ACU 410- 22 | 3 | 9.2
ACU 410- 23 | 4 | 11
ACU 410- 25 | 4 | 15
ACU 410- 27 | 5 | 18.5
ACU 410- 29 | 5 | 22
ACU 410- 31 | 5 | 30
ACU 410- 33 | 6 | 37
ACU 410- 35 | 6 | 45
ACU 410- 37 | 6 | 55

ACU 410- 39 | 6 | 65

ACU 410- 43 | 7 | 75
ACU 410- 45 | 7 | 90
ACU 410- 47 | 7 | 110
ACU 410- 49 | 7 | 132
ACU 410- 51 | 7 | 160
ACU 410- 53 | 7 | 200
ACU 410- 51 | 8 | 160
ACU 410- 53 | 8 | 200
ACU 410- 55 | 8 | 250
ACU 410- 57 | 8 | 315
ACU 410- 59 | 8 | 355
ACU 410- 61 | 8 | 400
TYPES & POWERS (ACU 510)

Type | Size | Power kW*
ACU 510- 51 | 8 | 160
ACU 510- 53 | 8 | 200
ACU 510- 55 | 8 | 250
ACU 510- 57 | 8 | 315
ACU 510- 59 | 8 | 355
ACU 510- 61 | 8 | 400
TYPES & POWERS (ACU 610)

Type | Size | Power kW*
ACU 610- 51 | 8 | 160
ACU 610- 53 | 8 | 200
ACU 610- 55 | 8 | 250
ACU 610- 57 | 8 | 315
ACU 610- 59 | 8 | 355
ACU 610- 61 | 8 | 400
