Loadcell Unipulse tại việt nam – Loadcell Unipulse nhật bản – Loadcell nhật bản

SCB High stiffness and high response loadcell

Product outline

“Virtually unbreakable!” – loadcell with an innovative concept! A strain gauge sensor with phenomenal rigidity and responsiveness.

■Capacity 100 N / 200 N / 500 N / 1 kN / 2 kN / 5 kN / 10 kN / 20 kN / 50 kN / 100 kN / 200 kN

■Phenomenal rigidity is achieved for a strain gauge type sensor!

■Safe overload of 500％

■Easy replacement

■High responsiveness

Lineup (100, 200, 500, 1k, 2k, 5k, 10k, 20k, 50k, 100k, 200k N)

Specifications

Model	SCB-□KN　^※1
Rated capacity	100, 200, 500	1k, 2k, 5k,10k, 20k, 50k, 100k, 200k	N
Rated output	0.4±0.1%　^※2		mV/V
Safe overload	500		%R.C.
Zero balance	±0.2		%R.O.
Non-linearity	0.2		%R.O.
Hysteresis	0.2		%R.O.
Repeatability	0.1		%R.O.
Compensated temperature range	-10 to +60		℃
Safe temperature range	-20 to +70		℃
Temperature effect on zero	0.015		%R.O./℃
Temperature effect on span	0.01		%R.O./℃
Input resistance	Approx. 700	Approx. 1000	Ω
Output resistance	Approx. 700	Approx. 1000	Ω
Recommended excitation voltage	5	10	V
Max. excitation voltage	7.5	15	V
Insulation resistance (DC50V)	1000 or more		MΩ
Deflection at rated capacity	0.015	1k:0.015 2k:0.020 5k:0.025 10k:0.025 20k:0.035 50k:0.065 100k:0.100 200k0.100	mm
Natural frequency	40	1k, 2k, 5k, 10k, 20k:26 50k, 100k:15 200k:8	kHz
Loadcell material	Stainless steel
Weight	0.02	1k, 2k, 5k:0.2 10k, 20k:0.4 50k:2.0 100k:2.3 200k:8.2	kg
Cable color code	＋EXC : Red ＋S : Yellow －S : Orange －EXC : Black ＋SIG : Green －SIG : White SHIELD : Blue
RoHS directives	2011/65/EU (EU)2015/863

※1　□:Rated capacity
※2　There are several restrictions on the flatness of fitting surface, the thickness of mounting plate, and tightening torque.
Please note that specifications or designs may vary due to our continuous product improvement activities.
