Checkline QuintSonic-T 80-165-0004 Checkline ElektroPhysik Vietnam – Pitesco cung cấp chính hãng giá tốt nhất QuintSonic-T Ultrasonic Multi-layer Thickness Gauge with Tablet Display

100% EU Origin	Checkline/ ElektroPhysik Vietnam	Model: 80-165-0004 Description: QuintSonic-T Ultrasonic Multi-layer Thickness Gauge with Tablet Display
100% EU Origin	Checkline/ ElektroPhysik Vietnam	Model: 41-164-0000 Description: Calibration Cert for QuintSonic, traceable to Dakks / PTB

80-165-0004 Máy đo độ dày đa lớp siêu âm QuintSonic-T với màn hình máy tính bảng

The QuintSonic-T is a Multi-Layer Ultrasonic Coating Thickness Gauge, specially designed for non-destructive coating thickness measurements of up to 8 layers of paint, primer, and other coatings applied on plastic, composites, metal, and other materials. Total thickness, as well as individual layer thickness, can be measured in one simple process.Featuring a large 8-inch display, the QuintSonic T offers a user-friendly overview of the measurement as well as the corresponding view of the ultrasonic signal (A-scan). Parameters for signal adjustment are displayed simultaneously and can be adjusted for the current measurement quickly and easily. Comprehensive data management of measuring values allows for data output in text and Excel format as well as creation of complete measurement reports in pdf format. The integration of descriptive texts and photos supports the documentation of measurement data. Additionally, the software allows for the storage of individual A-scans for subsequent adjustment of clipping domains or blocked domains.

The QuintSonic T is ideal for harsh environments thanks to an IP 67 & MIL-STD 810 G rating and extremely strong Gorilla® glass.

Features

Non-destructive coating thickness measurements
Up to 7.5mm / .29 Inches depending on material
Large and Rugged Tablet Display Included
Measurement of the total thickness as well as the individual layer thickness of a multi-layer system in only one operation
Storage for measurements, statistics, and material calibrations

Measuring range / Resolution / Accuracy	Layer 1: Measuring range 356 µm Resolution 0,25 µm Accuracy 0,25 µm Layer 2: Measuring range 890 µm Resolution 0,5 µm Accuracy 0,5 µm Layer 3: Measuring range 1.900 µm Resolution 1 µm Accuracy 1 µm Layer 4: Measuring range 3.900 µm Resolution 2 µm Accuracy 2 µm Layer 5: Measuring range 7.500 µm Resolution 4 µm Accuracy 4 µm (at 2375 m/s ultrasonic velocity in all layers)
Min Layer Thickness	Approx. 10 µm / 0.3 mils (depending on the ultrasonic velocity in the layer)
Min Measuring Area	5 mm Ø / 0.2″ Ø
Measurement Time	approx. 1 s
Statistical functions (per batch):	n, min, max, mean value, standard deviation, coefficient of variation, block statistics (normconforming / user adjustable), histogram, trend diagram
Minimum curvature radius	convex: 50 mm / 2″ concave: NA
Measuring units	μm, mm, mils, inch
Operating Temperature	+5…50°C
Storage Temperature	-10…+50°C
Data ports	IrDA 1.0, USB and RS232 via adapter cable (available as an option)
Power supply	4 x AA batteries, Optional AC Adapter
Display	160 x 160 pixel LCD, backlit
Dimensions	153 mm x 89 mm x 32 mm (basic unit); dia. 25 mm x length 60 mm (sensor)
Weight	310 g (basic unit incl. batteries), 80g (sensor)
Interface	Bluetooth, WiFi ,SD-card
