Cảm biến bức xạ Si-RS485TC-T-Tm Mencke & Tegtmeyer GmbH Viet Nam

Silicon solar irradiation sensors (Reference cells or Si sensors) offer an economical but robust and reliable solution for measuring solar irradiance levels, particularly for monitoring photovoltaic systems. The design of the sensor element, which corresponds to that of a photovoltaic module, make these sensors ideally suited as a reference for monitoring photovoltaic systems.

In addition to a wide range of standard types, we also offer customer-specific solutions on request. Simply send us your inquiry.

Typ	Measurment Uncertainty IEC61724-1	Supply	Temperature Compensation	Irradiance Signal 0…1500 W/sqm	Cell Temperature Signal -40…+90°C
Si-V-1.5TC-batt-D / -E¹	Class A	battery	yes	0…1.5 V	—
Si-V-1.5TC	Class A	4…28 Vdc	yes	0…1.5 V	—
Si-V-1.5TC-T	Class A	5.5…28 Vdc	yes	0…1.5 V	0…2 V
Si-mV-85	Class A	none	no	0…approx. 85 mV	—
Si-mV-85-Pt100 / -4L²	Class A	none	no	0…approx. 85 mV	Pt100
Si-mV-85-Pt1000 / -4L²	Class A	none	no	0…approx. 85 mV	Pt1000
Si-I-420TC	Class A	12…28 Vdc	yes	4…20 mA	—
Si-I-420TC-T	Class A	12…28 Vdc	yes	4…20 mA	4…20 mA
Si-V-10TC	Class A	12…28 Vdc	yes	0…10 V	—
Si-V-10TC-T	Class A	12…28 Vdc	yes	0…10 V	0…10 V
Si-RS485TC-T	Class A	10…28 Vdc	yes	RS485	RS485
Si-RS485TC-2T³	Class A	10…28 Vdc	yes	RS485	RS485
Si-RS485TC-3T⁴	Class A	10…28 Vdc	yes	RS485	RS485
Si-RS485TC-T-Tm⁵	Class A	10…28 Vdc	yes	RS485	RS485
Si-RS485TC-2T-v⁶	Class A	10…28 Vdc	yes	RS485	RS485
